Aluminum Standoffs
  • SKU:

Aluminum Standoffs

Standoffs are like spacers, but the internal hole is threaded in order for a machine screw to thread into them for a strong and tight fit. Aluminum standoffs can be used to connect important components in your robot, and our variety of sizes gives you everything you need to make small gearboxes all the way up to large shooter hoods! The aluminum standoffs:


  • Are tapped 10-32 on both ends
  • Come in lengths of 2”, 3”, 4”, 5”, 6”, 7”, and 8”
  • Have a ⅜” hex profile so that users can use a wrench to hold the standoff while tightening screws

Use the standoffs straight out of the box, or turn them down to a size that works for you! Our aluminum standoffs are guaranteed to make your robot build easier!

$4.99
P/N Description Material CAD Drawings Weight
WCP-0230 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 2" WD) 6061-T6 Aluminum STEP PDF 0.020 lbs
(Per Shaft)
WCP-0312 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 3" WD) 6061-T6 Aluminum STEP PDF 0.031 lbs
(Per Shaft)
WCP-0313 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 4" WD) 6061-T6 Aluminum STEP PDF 0.043 lbs
(Per Shaft)
WCP-0314 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 5" WD) 6061-T6 Aluminum STEP PDF 0.054 lbs
(Per Shaft)
WCP-0315 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 6" WD) 6061-T6 Aluminum STEP PDF 0.066 lbs
(Per Shaft)
WCP-0316 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 7" WD) 6061-T6 Aluminum STEP PDF 0.078 lbs
(Per Shaft)
WCP-0317 Aluminum Threaded Hex Standoffs (.196" ID x 3/8" OD x 8" WD) 6061-T6 Aluminum STEP PDF 0.090 lbs
(Per Shaft)

WCP-0599 Aluminum Threaded Hex Standoffs (#10-32 ID x 1/2" OD x 2-1/2" WD) 7075-T6 Aluminum STEP PDF 0.050 lbs
WCP-0575 Aluminum Threaded Hex Standoffs (#10-32 ID x 1/2" OD x 3-1/2" WD) 7075-T6 Aluminum STEP PDF 0.070 lbs
WCP-0506 Aluminum Threaded Hex Standoffs (#10-32 ID x 1/2" OD x 4" WD) 7075-T6 Aluminum STEP PDF 0.080 lbs
WCP-0573 Aluminum Threaded Hex Standoffs (#10-32 ID x 1/2" OD x 4-1/2" WD) 7075-T6 Aluminum STEP PDF 0.090 lbs
