#25 Sprockets

Sprockets are profiled wheels with teeth that mesh with chain to transfer motion. Our sprockets are custom manufactured out of high strength aluminum, black anodized for superior performance. Plate sprockets include WCP MotionX pattern!

  • Plate sprockets are 7075-T6 aluminum
  • Hub sprockets are 7075-T6 aluminum
  • Number of teeth laser engraved on each sprocket
  • Compatible with either #25 or #25H Roller Chain
  • Now able to run chain easily through tube with our chain in tube sprockets

Access User Guide, Kit Contents & More!

$7.99
P/N Description Material CAD Onshape Drawings Weight
WCP-1019 10T Steel Double Hub Sprocket (#25 Chain, 8mm SplineXS Bore) 4140 Steel STEP Link PDF 0.025 lbs
WCP-1020 12T Steel Double Hub Sprocket (#25 Chain, 8mm SplineXS Bore) 4140 Steel STEP Link PDF 0.032 lbs
WCP-1419 10t Steel Double Hub Sprocket (#25 Chain, 8mm Key Bore) 4140 Steel STEP - PDF 0.024 lbs
 WCP-0582 10t Steel Double Hub Sprocket (#25 Chain, Falcon Spline Bore) 4140 Steel STEP Link PDF 0.023 lbs

WCP-0576 12t Steel Double Hub Sprocket (#25 Chain, 1/2" Rounded Hex Bore) 4140 Steel STEP Link PDF 0.026 lbs
WCP-0577 14t Steel Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 4140 Steel STEP Link PDF 0.039 lbs
WCP-0578 16t Steel Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 4140 Steel STEP Link PDF 0.048 lbs
WCP-0558 16t Aluminum Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.017 lbs
WCP-0579 17t Aluminum Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.019 lbs
WCP-0559 18t Aluminum Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.021 lbs
WCP-0580 20t Aluminum Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.025 lbs
WCP-0560 22t Aluminum Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.029 lbs
WCP-0581 24t Aluminum Double Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.035 lbs

WCP-0754 18t Aluminum Hub Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP - PDF 0.028 lbs

WCP-0087 16t Aluminum Hub Double Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.026 lbs
WCP-0088 17t Aluminum Hub Double Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.029 lbs
WCP-0089 18t Aluminum Hub Double Sprocket (#25 Chain, 1/2" Hex Bore) 7075-T6 Aluminum STEP Link PDF 0.034 lbs

217-5833 16T Aluminum Hub Sprocket (#25 Chain, 3/8" Hex Bore) 7075-T6 Aluminum STEP - PDF 0.028 lbs
217-5834 18t Aluminum Hub Sprocket (#25 Chain, 3/8" Hex Bore) 7075-T6 Aluminum STEP - PDF 0.031 lbs
217-5835 22t Aluminum Hub Sprocket (#25 Chain, 3/8" Hex Bore) 7075-T6 Aluminum STEP - PDF 0.041 lbs

WCP-0964 24t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.020 lbs
WCP-0965 30t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.037 lbs
WCP-0966 36t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.055 lbs
WCP-0967 42t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.080 lbs
WCP-0968 48t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.114 lbs
WCP-0969 54t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.151 lbs
WCP-0970 60t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.163 lbs
WCP-0971 66t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.186 lbs
WCP-0972 72t Aluminum Plate Sprocket (#25 Chain, SplineXL Bore) 7075-T6 Aluminum STEP Link PDF 0.209 lbs
