Our Round Roller System gives teams a modular way to create virtually any kind of roller. This Roller System is available in high-strength aluminum to create a light-weight and robust roller system for your robot.
| P/N | Description | Material | CAD | Onshape | Drawings | Weight |
| WCP-1270 | .875" ID x 1" OD Aluminum Round Tube Stock (47") | 6061-T6 Aluminum | STEP | Link | 0.837 lbs | |
| WCP-1271 | 1.125" ID x 1.25" OD Aluminum Round Tube Stock (47") | 6061-T6 Aluminum | STEP | Link | 1.060 lbs | |
| WCP-1389 | 1-1/8" OD Aluminum Roller Hub (5/16-18 Tapped Bore) | 6061-T6 Aluminum | STEP | Link | 0.042 lbs | |
| WCP-1390 | 7/8" OD Aluminum Roller Hub (5/16-18 Tapped Bore) | 6061-T6 Aluminum | STEP | Link | 0.026 lbs | |
| WCP-1238 | 1-1/8" OD Aluminum Roller Hub (1/2" Hex Bore) | 6061-T6 Aluminum | STEP | Link | 0.034 lbs | |
| WCP-1239 | 7/8" OD Aluminum Roller Hub (1/2" Hex Bore) | 6061-T6 Aluminum | STEP | Link | 0.017 lbs | |
| WCP-1396 | 1/2" Hex OD x 3" L Roller Hub Hex Insert (5/16-18 Tapped) | 7075-T6 Aluminum | STEP | Link | 0.066 lbs | |
| WCP-1397 | 1/2" Hex OD x 1-1/4" L Roller Hub Hex Insert (5/16-18 Tapped) | 7075-T6 Aluminum | STEP | Link | 0.029 lbs | |
| WCP-0443 | 1.75" Roller Flange (1" ID Roller) (2-Pack) | 6061-T6 Aluminum | STEP | Link | 0.019 lbs | |
| WCP-0444 | 2" Roller Flange (1.25" ID Roller) (2-Pack) | 6061-T6 Aluminum | STEP | Link | 0.022 lbs | |
| WCP-0779 | 0.375" ID x 0.875" OD x 0.280" WD (Flanged Bearing) | Steel | STEP | Link | 0.031 lbs | |
| WCP-0106 | WCP Roller Shoulder Bolt (2-Pack) | 6061-T6 Aluminum | STEP | Link | 0.065 lbs | |
| WCP-0104 | WCP Roller End Plate (2-Pack) | 6061-T6 Aluminum | STEP | Link | 0.051 lbs | |
| WCP-0105 | WCP Roller Center Plate (2-Pack) | 6061-T6 Aluminum | STEP | Link | 0.051 lbs |
